Centerless Grinder ESTARTA 301 # 4385
Centerless Grinder ESTARTA 301 # 4385
Location:Badajoz, Spain
or
Call +34 924 500 336
Specifications
| Manufacturer | ESTARTA |
| Model | 301 |
| Condition | Used |
| Stock Number | 4385 |
| Grinding wheel gap | 1.5 / 50 mm |
| Max.width of wheel in feed grinding | 125 mm |
| Working wheel dimensions (od x id x width) | 325x175x125 mm |
| Øext.min. working wheel | 220mm |
| Max. profile depth of the working wheel | 8 mm |
| Regulating wheel speed nº | infinite |
| Infeed (auto / manual) | Automatic / Automatic |
| Driving wheel dimensions (od x id x width) | 220 x 125 x 125 mm |
| Øext.min. driving wheel | 165 mm |
| Working wheel motor power | 7,5 Kw |
| Driving wheel motor power | 0.75 Kw |
| Angle of inclination of the working grinding head | +/- 5º |
| Angle of inclination of the drive wheel head | -2/+5º |
| Long | 1.520 mm |
| Width | 1.020 mm |
| High | 1.260 mm |
| Weight | 1.550 Kg |
